Description
Basic Specifications
– Connector Type: Socket
– Cable Assembly: No
– Safety Standards: C-UL/CSA, UL
– Number of Positions: 4
– Number of Rows (Interface): 2
– Contact Pitch: 2.0 mm
– Connector Length: 6.0 mm
– Connector Width: 5.0 mm
– Connector Height: 7.3 mm
– Staggered Lead: No
– Housing Color: Black
– Wire Termination Method: Crimping
– Recommended Wire Type: Discrete wire
– Recommended Min. Wire Size (AWG): 30
– Recommended Max. Wire Size (AWG): 22
– Operating Temperature: -40°C to 85°C
Mechanical Specifications
– Locking Style: Friction
Electrical Specifications
– Rated Current: 2.0 A
– Rated Voltage (AC): AC 250.0 V
– Rated Voltage (DC): DC 250.0 V
– Withstanding Voltage: 650 V Max.
