Description
Basic Specifications
– Connector Type: Socket
– Cable Assembly: No
– Safety Standards: UL
– Number of Positions: 15
– Number of Rows (Interface): 1
– Contact Pitch: 1.25 mm
– Connector Length: 20.7 mm
– Connector Width: 5.8 mm
– Connector Height: 2.3 mm
– Connector Orientation: Straight
– Housing Color: Beige
– Wire Termination Method: Crimping
– Recommended Wire Type: Discrete wire
– Recommended Min. Wire Size (AWG): 32
– Recommended Max. Wire Size (AWG): 26
– Operating Temperature: -35°C to 85°C
Mechanical Specifications
– Locking Style: Friction
– Key: No
Electrical Specifications
– Rated Current: 1.0 A
– Rated Voltage (AC): AC 150.0 V
– Withstanding Voltage: 500 V Max.
– Performance Characteristics: LVDS
