Description
The SN04-D1 inductive sensor is a reliable non-contact metal object detector with a PNP NO (Normally Open) output. Thanks to its compact design, high durability and universal 1030 V power supply, it is suitable for a wide range of automation applications where accurate and fast detection of metal objects is required.
Technical specifications
Detection distance: 5 mm ±10%
Adjustable switching distance: approx. 04 mm
Output type: PNP, NO (Normally Open)
Supply voltage: DC 10-30V
Maximum output load: 200 mA
Case dimensions: 18 × 18 × 34.4 mm
Sensor height: 13.6 mm
Weight: 50 g
Protection level: IP67
Material: ABS plastic (body)
Operating temperature: 25 °C to +60 °C
Switching frequency: 0.5 kHz
Shock and interference resistance: AC1000 V / 50-60 Hz (1 min between parts)
Cable: integrated, length typically 11.2 m
Functions and features
Non-contact sensing of metal objects without mechanical wear.
The compact design allows installation even in confined spaces.
PNP NO output switches on when a metal object approaches.
Universal 10-30V DC power supply for most industrial applications.
High reliability and resistance to moisture and dust (IP67).
Fast response for accurate detection of fast moving parts.
Ideal for
Automation lines and robotic assemblies.
Detection of metal parts on conveyors.
Checking the position, presence or passage of parts.
Modernization of older machines (retrofit) thanks to universal connection.
Package contents
1× inductive sensor SN04-D1 (PNP NO)
Why choose this product?
The SN04-D1 combines high detection accuracy, long life and IP67 protection in a compact design. The PNP NO variant is ideal for control systems where the signal should only be active when a metal object approaches. Its robust design and easy installation make this sensor a reliable choice for industrial automation.
