Description
Waterproof laser module with a green beam with a wavelength of 520 nm designed for precise line projection. The green light is very visible even in higher ambient light, making it an ideal choice for industrial and outdoor applications. Thanks to the IP67 protection, the module is dust and water resistant and suitable for use in harsh operating conditions. Glass optics allow fine focusing of the line width with subsequent mechanical fixation.
Technical specifications
Wavelength: 520 nm (green)
Beam shape: line
Beam angle: 110°
Optical power (variants): 10 mW, 30 mW, 50 mW, 80 mW, 135 mW
Operating mode: CW (continuous light)
Current control: APC
Supply voltage: 5V DC
Operating current: < 500 mA
Connector type: DC 5.5×2.1mm/5.5×2.5mm
Cable length: 100 cm
Housing material: aluminum
Optics material: glass
Module dimensions: diameter 20 mm × length 90 mm
Weight: 65g
Protection: IP67
Operating temperature: -10°C to +50°C
Storage temperature: -40°C to +85°C
Mean Time to Failure (MTTF):> 8,000 hours
Functions and features
Waterproof design with IP67 protection
High visibility green beam 520nm
Focusable glass optical lens
Focus lock using the locking ring
Stable performance thanks to APC/ACC regulation
Possibility to adjust the width of the projection line
Robust aluminum housing with effective heat dissipation
Ideal for
Laser positioning and guidance
Industrial marking and control systems
Outdoor applications with high visibility requirements
Alignment of machines and production lines
Construction, assembly and geodetic works
Measurement and calibration systems
Package contents
Waterproof 520nm laser module
Why choose this product?
IP67 protection for use in harsh environments
Excellent visibility of the green laser even in daylight
Accurate and stable line projection
Fine mechanical focusing option
Long life and professional construction
Wide range of performance options
