Description
Compact recessed LED luminaire designed for orientation and decorative lighting in exterior and interior. Thanks to IP67 protection, it is suitable for installations exposed to moisture and dust, for example in terraces, stairs, floors or garden elements. The power supply is provided by a safe voltage of DC 12 V and the luminaire is equipped with a connection cable with a waterproof connector.
Technical specifications
Power consumption: 0.8 W
Luminous flux: 80 lm
CRI: 85
Power supply: DC 12V
Protection: IP67
Body material: aluminum
Body dimensions: Ø26 × 38 mm
Mounting hole: Ø18mm
Cable: 2x (IN/OUT) 36 cm with waterproof connector
Working temperature: -25°C to +45°C
Color Rendering Index (CRI): 88
Light color (depending on variant): white 60006500 K, natural white 40004500 K, warm white 30003500 K, green, blue, red
Certification: CE, RoHS
LED chip lifespan: 35000 h
Functions and features
Flush mounting for a clean and mechanically protected installation
Aluminum body for heat dissipation and stable operation under normal conditions
IP67 protection for use in water and dusty environments
DC 12 V power supply suitable for low voltage distribution systems
Selection of light colors according to the desired application
Ideal for
Lighting of terraces and wooden floors
Staircase and orientation lighting
Garden and landscape installations
Floor and recessed decorative lighting
Indication and DIY projects with DC 12 V power supply
Package contents
Recessed LED light 1 W
Why choose this product?
Defined IP67 protection for outdoor and humid environments
Compact dimensions for installations with limited space
DC 12 V power supply for low voltage applications
Large selection of color temperature or color depending on the variant
Installation and operating instructions
For proper operation, it is necessary to use a stabilized 12 V DC power supply with sufficient current reserve.
When installing, observe the correct polarity of the power supply and ensure a waterproof connection of the connector.
Adapt the countersunk hole and the method of attachment to the structure of the base so that there is no mechanical stress on the cable.
Outdoors, we recommend placing the power supply outside of humid environments or in an appropriate enclosure.
Safety notice
Perform installation with the power disconnected.
The lamp is designed for DC 12 V power supply; do not connect to mains voltage.
Do not use the luminaire with a damaged cable or connector.
