WK-688H – UNIVERSAL HIGH-PRESSURE DIGITAL MANOMETER FOR REFRIGERANT GASES
Digital manometers use high-accuracy sensors to detect the pressures and working temperatures of 82 different types of refrigerants, including vacuum level monitoring.
FEATURES:
Quick selection with pressure/vacuum button
Database for 82 different refrigerants
Vacuum measurement with display in microns
Battery charge indicator
1/8″ NPT male threaded connection
SPECIFICATIONS:
|
Measurement Units |
Pressure: Psi / Kpa / bar / inHg / KgF/cm² / Torr Temperature: °F / °C |
|
Connections |
1/8 Npt |
|
Measurement Ranges |
Low Pressure / High Pressure: 0 6 Mpa, resolution 1 Kpa, accuracy ±0.5% of reading. |
|
Overpressure |
100 Bar, 10 Mpa. |
|
Refrigerants |
R11, R113, R114, R115, R116, R12, R123, R124, R125, R13, R134a, R14, R141b, R142b, R143a, R152a, R170, R21, R218, R22, R23, R290, R32, R401a, R401b, R401c, R402a, R402b, R403a, R403b, R404a, R405a, R406a, R407a, R407b, R407c, R407d, R407e, R408a, R409a, R409b, R41, R410a, R410b, R411a, R411b, R412a, R413a, R414a, R414b, R415a, R415b, R416a, R417a, R418a, R419a, R420a, R421a, R421b, R422a, R422b, R422c, R422d, R423a, R424a, R425a, R426a, R427a, R428a, R50, R500, R501, R502, R503, R504, R507a, R508a, R508b, R509a, R600, R600a, R717, R744 |
|
Operating Conditions |
Working temperature: -20 to +60°C Humidity: 10 90% R.H. |
|
Dimensions and Weight |
130x90x40 mm, 250g (without batteries). |
|
Batteries |
1 x 9V, 30 hours of continuous use without backlight. |
CONTENTS:
Digital manometer
Instructions in Italian
Battery not included
Product code: WK-688H
